philippi Fahrzeugleitung FLRY-B RT/SW
philippi · On-board installation
Vehicle cable FLRY-B RD/BK
The FLRY-B vehicle cable from philippi is a single-core, thin-walled copper cable for the 12 V and 24 V electrical systems of vehicles, motorhomes and off-road builds, available in red and black. It complies with ISO 6722 and is offered in eight cross-sections from 1.5 to 50 mm².
In detail. Vehicle cable FLRY-B RD/BK.
- Thin-walled insulation: saves space and weight in the wiring harness
- Fine-stranded copper conductor for tight bending radii
- Every cross-section in red and black
The cross-sections 1.5 to 6 mm² are available as a 10 cm piece, by the metre and in 100 m, the cross-sections 16 to 50 mm² by the metre and in 50 m.
Original equipment quality
- Individually tested: every unit is connected and tested in a test environment in Remseck.
- Brand-name components, as in series production for boatyards.
- Repairable for decades: spare parts up to 30 years back, own repair centre.
Technical data
| Feature | Value |
|---|---|
| Type | FLRY-B to ISO 6722 |
| Colours | Red, black |
| Cross-sections | 1.5 · 2.5 · 4 · 6 · 16 · 25 · 35 · 50 mm² |
| Temperature range | –40 to +105 °C |
| Rated voltage | 60 V DC |
| Lengths | 1.5–6 mm²: 10 cm, 1 m, 100 m; 16–50 mm²: 1 m, 50 m |
Manufacturer and product safety
philippi elektrische systeme GmbH
Neckaraue 19
71686 Remseck am Neckar
Deutschland
info@philippi-online.de
Safety information: see the operating manual and data sheet.
Frequently asked questions. Answered briefly.
Which system voltage is the FLRY-B suitable for?
The FLRY-B is intended for 12 V and 24 V electrical systems; its rated voltage is 60 V DC.
In which lengths is the FLRY-B available?
1.5 to 6 mm² is available as a 10 cm piece, by the metre and in 100 m, 16 to 50 mm² by the metre and in 50 m.
