philippi EMS5 Minus-Sammelschiene für die Rückführung der Verbraucherströme
philippi · On-board installation
Busbar EMS 4
The philippi busbar EMS 4 is a negative bar from the Power Install System 250 with 4 connections that serves as a central collection point for the negative cables in the onboard electrical system and replaces several individual connection points.
- Nickel-plated copper
In detail. Busbar EMS 4.
- 4 connections on one central negative busbar instead of many individual connections
- Current carrying capacity 250 A for clear, safe wiring
- Suitable for 12 V and 24 V onboard electrical systems on yachts, campers or off-road vehicles
The EMS 4 is part of the philippi Power Install System 250 and brings order to the negative side of the onboard electrical system: instead of many individual cable lugs on one battery terminal, all negative cables are brought together neatly and clearly on the busbar. In combination with the shunts SHE or SHX and matching connecting links (SDV), several consumer circuits can also be monitored safely.
Original equipment quality
- Individually tested: every unit is connected and tested in a test environment in Remseck.
- Brand-name components, as in series production for boatyards.
- Repairable for decades: spare parts up to 30 years back, own repair centre.
Technical data
| Connections | 4 (negative bar) |
|---|---|
| Current carrying capacity | 250 A |
| Connection bolts | M10 |
| Dimensions | L 212 x W 40 x H 50 mm |
| Article number | 082000140 |
Manufacturer and product safety
philippi elektrische systeme GmbH
Neckaraue 19
71686 Remseck am Neckar
Deutschland
info@philippi-online.de
Safety information: see the operating manual and data sheet.
Frequently asked questions. Answered briefly.
What is the EMS 4 needed for?
It serves as a central negative busbar in the onboard electrical system and replaces several individual connection points on the battery with a clear, safe distribution.
