Blue Sea Cover for MaxiBus 2127/2128
The MaxiBus 2127/2128 cover (cover 2719) from Blue Sea Systems, available from philippi, is a protective housing made of durable plastic with a frosted hood for the 250 A MaxiBus busbars SMS 2127 and SMS 2128. It insulates the terminal studs and meets ABYC insulation requirements.
- Nickel-plated copper busbars
- Robust construction
In detail. Blue Sea Cover for MaxiBus 2127/2128.
- Insulating cover with cut-outs for easy cable routing
- Meets ABYC insulation requirements for busbars
The MaxiBus SMS 2127 has 4 5/16" stud terminals, the MaxiBus SMS 2128 has 6 #10-24 screw terminals and 2 5/16" stud terminals. Both busbars measure L 149 x W 38 x H 43 mm.
Technical data
| Feature | Value |
|---|---|
| Suitable for | MaxiBus SMS 2127 and SMS 2128 (250 A) |
| Dimensions | L 170 x W 64 x H 64 mm |
| Mounting hole spacing | 104.1 mm (4.10") |
| Material | durable plastic, frosted hood |
| Order No. | 7 0012 2719 |
Manufacturer and product safety
Navico Group Americas LLC (brand Blue Sea Systems)
N85 W12545 Westbrook Crossing
Menomonee Falls, WI 53051
USA
www.bluesea.com/contact
Safety information: see the operating manual and data sheet.
Frequently asked questions. Answered briefly.
Does cover 2719 also fit the SMS 2105 or SMS 2126?
No. For the longer MaxiBus SMS 2105 and SMS 2126 (L 197 mm), cover 2718 is intended; the 2719 belongs to the 149 mm long SMS 2127 and SMS 2128.
